Through hole drill bit
Your present position is:Details
Through hole drill bit-Through hole drill bit—AUYA-I
Advantages:
      1、Better drilling due to V- point design
      2、Longer working life due to special cutting part
      3、Better chip evacuation thanks to four grooves design
      4、Protection of the hole edge upon exacting thanks to spiral with back guide
      5、Safe drilling thanks to centering point which guarantees concentricity and balance
Details

Specification And Model

57.5mm
Code Overall length(mm) Diameter(mm) Shank(mm) Rotation (R/L)
57.5 3.0 10*27 R/L
57.5 4.0 10 R/L
57.5 5.0 10 R/L
57.5 6.0 10 R/L
57.5 7.0 10 R/L
57.5 8.0 10 R/L
57.5 9.0 10 R/L
57.5 10 10 R/L
57.5 11 10 R/L
57.5 12 10 R/L
57.5 13 10 R/L
57.5 14 10 R/L
57.5 15 10 R/L
70mm
Code Overall length(mm) Diameter(mm) Shank(mm) Rotation (R/L)
70 3.0 10*27 R/L
70 4.0 10 R/L
70 5.0 10 R/L
70 6.0 10 R/L
70 7.0 10 R/L
70 8.0 10 R/L
70 9.0 10 R/L
70 10 10 R/L
70 11 10 R/L
70 12 10 R/L
70 13 10 R/L
70 14 10 R/L
70 15 10 R/L
* Customization available.
