Brad point drill bit
Your present position is:Details
Brad point drill bit-Brad point drill bit—AUYA-III
Advantages:
      1、Special cutting design greatly improves it's tensile strength and working life
      2、Super hard carbide especially suitable for hard materials
      3、Excellent stability and safe drilling thanks to centering point
      4、Protection of the hole edge upon exacting thanks to spiral with back guide
      5、Big spiral angle design makes chip evacuation smoother, especially for high speed operation
Details

Specification And Model

57mm
Code Overall length(mm) Diameter(mm) Shank(mm) Rotation (R/L)
660300572 57.5 3.0 10*27 R/L
660400572 57.5 4.0 10 R/L
660500572 57.5 5.0 10 R/L
660600572 57.5 6.0 10 R/L
660800572 57.5 8.0 10 R/L
661000572 57.5 10.0 10 R/L
70mm
Code Overall length(mm) Diameter(mm) Shank(mm) Rotation (R/L)
660300702 70 3.0 10*27 R/L
660400702 70 4.0 10 R/L
660500702 70 5.0 10 R/L
660600702 70 6.0 10 R/L
660800702 70 8.0 10 R/L
661000702 70 10.0 10 R/L
* Customization available.
